Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machines. They manufacture equipment like manlifts, boom lifts and aerial lifts. These types of machinery are designed to facilitate access to hard to reach places, large equipment, buildings and roofs, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves only in one direction and includes steps or handholds or paltforms that are attached to the unit in order to move workers from every floor.
TB85
Terex's TB85 man lift offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height measures at 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
